Compatible with both automatic insert and flat release for PV module sorting;
The clamping jaws of the grabbing units adopt a pneumatis insertion and clamping structure, which is reliable and does not scratch the module frame;
The grasping manipulator adopts a double-set design to improve the speed of binning;
The lifting displacement device has the function of holding the brake to ensure that it will not fall down.
| Model | VSR60A |
| Applicable module size | L1630-2600mm, W950-1450mm |
| Lumber of pallet | 6 (It can be customized) |
| Cycle | <20s |
| Pick up weight | 50kgs |
| Yield | 99.9% |
| Rated power | 20kW |
| Air consumption | 50L/min |
| N.W. | 9.4T |
| Dimension (6 grades) | L17300mm*W4175mm*H3800mm |
