String soldering, layup,and bussing are highlyintegrated, saving space.
1:1:1 configuration for string soldering, layout, and bussing improvesoverallline utilization.
Reduce the number of cell pickups, significantly lowering the risk of cellcracking.
Alignment corrections are integrated into the layup section, making adjust.ments more convenient.
Highly cost-effective for small to medium-scale production lines
|
Cell size |
156-230mm,5-20BB，1/2，1/3cell |
|
Glass size |
L1630-2600mm,w960-1450mm |
| Stringer cycle |
10000 half-cell/hour |
|
Layup and bussing cycle |
36s (6s/string for each side) |
|
Layup and bussingyield |
98% |
| Layup accuracy |
±0.3mm |
| Rated power |
73kW |
|
Air Consumption |
6300L/min |
| N.W. |
20500kgs |
| Dimension |
L15300mm*W3750mm*H2600mm |
